Stable construction
Very low installation height: 110 mm
All trolleys with the same installation height can be combined with one another
Long-term tested roles with long durability
Handlebars with towing eyes made of particularly robust materials
| Technical data | F6 | L6 |
|---|---|---|
| item number | 10208 | 10209 |
| Installation height in mm / number of rollers (85x85mm) | 110 / 8 | 110 / 8 |
| Support surface per cassette in mm | 200x220 | - |
| Connecting rod in mm | 1030 | - |
| Turntable ø / steering angle | - | 170 / ± 90 ° |
| Handlebar in mm | - | 1080 |
| External dimensions (L x W) mm | - | 610x520 |
| Dead weight in kg | 31 | 46,4 |
| Load in kN / t | 60 / 6 | 60 / 6 |
| Total load in kN / t | 120/12 (F6 + L6) |
