Lifting device V30-EX
30 t full load capacity

Features of the hydraulic jack / machine jack V30-EX

  • Ideal for hard-to-reach places and when a safety distance is required
  • It is operated using the PV hand pump (up to two lifting devices), the PE electric pump (up to four lifting devices) or the Q60 synchronous printing unit
  • Without own hydraulics















Technical data V30-EX

designation Values
item number 11140
Full load kN / t 300 / 30
Working pressure bar 430
Smallest attachment height by means of a bracket mm 40
Lifting height mm 156
Adjustability of the strap 2 x
Attachment height by means of head plate mm 330
External dimensions (L x W x H) mm 454 x 400 x 330
Dead weight in kg 110,8
